STR Series Refrigeration Laser Welders — New for 2026
Dual-Loop Refrigerant Cooling · 100% Duty Cycle · −30°C (−22°F) to +60°C (140°F)
Next-generation dual-loop refrigerant cooling — built for extreme environments
Five models, two series. The STR delivers stable laser output from −30°C (−22°F) to +60°C (140°F) with Power Compensation Adaptive Correction keeping power fluctuation under 1% for the life of the machine.
- Dual-loop refrigerant direct cooling — 100% duty cycle
- Stable operation from −30°C (−22°F) to +60°C (140°F) (tested at −19.9°C (−3.8°F) and 71°C (160°F))
- IPX3 waterproof · IP5X dustproof
- Power compensation adaptive correction — fluctuation < 1%
- All-in-one intelligent control with K Series welding torch
- Integrated expert welding process library (> 20 process packages)
- Ultra-flexible integrated armored cable — 5 m or 10 m
- Available in 900W, 1200W, 1500W, 2000W, and 3000W
STR-LITE S Series — Expert of Lightweight Welding
The STR-LITE S series sets a new standard for lightweight handheld laser welding. Available in 900W (S30) and 1200W (S40), designed for sign shops and fabricators who need precise, portable welding with industrial-grade reliability.
- All-in-one intelligent control — simplified operation for any skill level
- Revolutionized user experience — intuitive interface, fast setup
- K Series welding torch — precision and comfort in a lightweight package
- Ultra-flexible integrated armored cable — 5 m standard, customizable length
- Integrated expert welding process library — over 20 pre-configured process packages
- Intelligent safety guard — built-in protections for safe daily operation
STR-MASTER X Series — Engine of Smart Industrial Welding
The STR-MASTER X series delivers industrial-grade performance for high-volume production. Available in 1500W (X50), 2000W (X60), and 3000W (X80), with support for automated welding, laser cleaning, and cutting.
- Industrial-grade performance — up to 3000W laser power
- 1+N Smart Ecosystem — scalable automation integration
- Intelligent welding process expertise — adaptive to material and joint type
- Flexible application expansion — cleaning, automated welding, cutting
- Extreme running stability — dual-loop refrigerant cooling at full continuous power
Why the STR Series
Industrial-grade quality assurance
Dual-loop refrigerant direct cooling — efficient and stable cooling for consistent performance across any environment. Unlike air-cooled systems that degrade above 15°C (59°F), the STR holds stable laser output all the way to 60°C (140°F).
Stable operation under extreme temperatures — tested at −19.9°C (−3.8°F) and 71°C (160°F). Rated for environments from −30°C (−22°F) to +60°C (140°F) operating, −40°C (−40°F) to +70°C (158°F) storage.
IPX3 waterproof — protected against water spray from any direction for shop-floor durability.
IP5X dustproof — dust-protected for long-term reliability in demanding industrial environments.
Power compensation adaptive correction technology
Over time, laser output naturally decreases. When the STR detects that power "Po" has fallen below the preset threshold "Ps", the system actively compensates — pushing output back up and maintaining consistent weld quality for the lifetime of the machine. Power fluctuation stays under 1%.
Stable laser output across all temperatures
The STR series maintains flat power output across its full operating range. Air-cooled welders lose significant power above 15°C (59°F). The dual-loop refrigerant system keeps the STR flat from −30°C (−22°F) to +60°C (140°F).
Spec sheet — STR-LITE S Series
| Specification | STR-LITE S30 | STR-LITE S40 |
|---|---|---|
| Rated Input Voltage | Single Phase 220V | |
| Input Power Frequency | 50/60 Hz | |
| Laser Power | 900W | 1200W |
| Rated Input Power | 3000W | 4000W |
| Welding Speed | 20 cm/min – 300 cm/min | |
| Cooling System | Dual-Loop Refrigerant Direct Cooling | |
| Operating Temperature | −30°C (−22°F) to +60°C (140°F) | |
| Storage Temperature | −40°C (−40°F) to +70°C (158°F) | |
| Operating Humidity | 0–90% | |
| Wire Diameter | 0.8 / 1.0 / 1.2 / 1.6 mm (0.031" / 0.039" / 0.047" / 0.063") | |
| Process Packages | > 20 | |
| Armored Cable Length | 5 m standard (customizable) | |
| Welding Mode | Continuous / Spot welding | |
| Dimensions (L×W×H) | 748 × 412 × 624 mm (29.4" × 16.2" × 24.6") | |
| Weight | 54 kg | |
Welding capability — STR-LITE S Series
| Material | STR-LITE S30 | STR-LITE S40 |
|---|---|---|
| Aluminum | 2 mm (0.079") | 3 mm (0.118") |
| Stainless Steel | 3 mm (0.118") | 4 mm (0.157") |
| Carbon Steel | 3 mm (0.118") | 4 mm (0.157") |
| Galvanized Sheet | 2 mm (0.079") | 3 mm (0.118") |
| Brass | 3 mm (0.118") | 3 mm (0.118") |
| Copper | 0.5 mm (0.020") | 1 mm (0.039") |
Spec sheet — STR-MASTER X Series
| Specification | STR-MASTER X50 | STR-MASTER X60 | STR-MASTER X80 |
|---|---|---|---|
| Rated Input Voltage | Single Phase 220V | Three Phase 380V | |
| Input Power Frequency | 50/60 Hz | ||
| Laser Power | 1500W | 2000W | 3000W |
| Rated Input Power | 5000W | 6800W | 10500W |
| Welding Speed | 20 cm/min – 300 cm/min | ||
| Cooling System | Dual-Loop Refrigerant Direct Cooling | ||
| Operating Temperature | −30°C (−22°F) to +60°C (140°F) | ||
| Storage Temperature | −40°C (−40°F) to +70°C (158°F) | ||
| Operating Humidity | 0–90% | ||
| Wire Diameter | 0.8 / 1.0 / 1.2 / 1.6 / 2.0 mm (0.031" / 0.039" / 0.047" / 0.063" / 0.079") | ||
| Process Packages | > 20 | ||
| Armored Cable Length | 5 m standard (customizable) | 10 m standard (customizable) | |
| Welding Mode | Continuous / Spot welding | ||
| Dimensions (L×W×H) | 912 × 420 × 722 mm (35.9" × 16.5" × 28.4") | 987 × 470 × 774 mm (38.9" × 18.5" × 30.5") | |
| Weight | 75 kg | 100 kg | |
Welding capability — STR-MASTER X Series
| Material | STR-MASTER X50 | STR-MASTER X60 | STR-MASTER X80 |
|---|---|---|---|
| Aluminum | 4 mm (0.157") | 5 mm (0.197") | 6 mm (0.236") |
| Stainless Steel | 5 mm (0.197") | 6 mm (0.236") | 8 mm (0.315") |
| Carbon Steel | 5 mm (0.197") | 6 mm (0.236") | 10 mm (0.394") |
| Galvanized Sheet | 4 mm (0.157") | 5 mm (0.197") | 7 mm (0.276") |
| Brass | 4 mm (0.157") | 5 mm (0.197") | 6 mm (0.236") |
| Copper | 2.5 mm (0.098") | 3 mm (0.118") | 4 mm (0.157") |
